驴小腿拉ise attachment Quick ConnectBlind
inMechanical Engineeringheld byAchillesLast seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
This contest is to design a fast way to connect and disconnect the Donkey Calf Raise attachment to various size smith machine barbell shafts. The Donkey Calf Raise attachment is a patented apparatus that can be attached to the smith machine barbell to perform the donkey calf raise exercise. The current design will not attach to all smith machine barbell shafts. I need a new quick way for the apparatus to attach to a 25mm to 35mm diameter smith machine barbell shaft.Please see attached 3D STEP file, Inventor assembly & part files and AutoCAD 3D file. Attached also are images on how to perform the donkey calf raise exercise.
Wants:
• A quick connect and disconnect to a smith machine barbell shaft• Commercial grade construction
• Must be very durable to withstand constant use
• Modern looking design
• It should be able to fit 25mm to 35mm diameter smith machine barbell shafts.
• Material: Aluminum
• All Designs will be 3D Solid Models
Don't Wants:
• Do not change the overall design; just change the way it connects to the smith machine barbell• We do not want overly complex designs that are difficult to manufacture. Keep it simple
Software:
- Software that can be used: • Autodesk Inventor, Pro Engineer, SolidWorks, Solid Edge, Catia, Unigraphics
Entries
1st Winner
#64驴小腿拉ise attachment Quick Connect AD002 - by Adriano BarissabyAdriano Ordoz Barissa
May 27, 2019 1:41
#59驴小腿拉ise attachment Quick Connect - by Adriano Ordoz BarissabyAdriano Ordoz Barissa
May 25, 2019 13:52
#65驴小腿拉ise attachment Quick Connect AD002 - by Adriano Ordoz BarissabyAdriano Ordoz Barissa
May 27, 2019 1:44
#46DCRA Quick Release & Connect (25mm-35mm Bars)byTom Garwood
Download Files
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render1
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render2
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render3
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render4
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render5
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render6
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render7
- Autodesk Fusion 360 2.0.5790 — Fusion360 - Render8
May 23, 2019 9:28
#6DCRA ATTACHMENT FOR 35mm TO 25mm BARSbyLickuidCAD
Declined
Download Files
- Bentley Microstation CONNECT — OVERVIEW 25mm
- Bentley Microstation CONNECT — OVERVIEW 35mm
- Bentley Microstation CONNECT — SIDEVIEW 25mm
- Bentley Microstation CONNECT — SIDEVIEW O 25mm
- Bentley Microstation CONNECT — SIDEVIEW 35mm
- Bentley Microstation CONNECT — SIDEVIEW O 35mm
- Bentley Microstation CONNECT — SIDEVIEW T 25mm
- Bentley Microstation CONNECT — SIDEVIEW T 35mm
- Bentley Microstation CONNECT — ISO T 25mm
- Bentley Microstation CONNECT — SIDEVIEW T 25mm
- Bentley Microstation CONNECT — SIDEVIEW T 35mm
- Bentley Microstation CONNECT — ASSEMBLY ISO PART
- Bentley Microstation CONNECT — PART DIM
May 1, 2019 23:20
#20modification for clasping a range of barbell diametersbyJeremy Benjamin
Download Files
May 6, 2019 5:44
Discussion
Hey CH,
Regarding the interface between the shaft and the DCRA connection, does the DCRA rotate around the shaft or will it be fixed i.e not rotate at all? Thanks.
Regarding the interface between the shaft and the DCRA connection, does the DCRA rotate around the shaft or will it be fixed i.e not rotate at all? Thanks.
Designer, I have received some good designs but nothing that I would call a winner yet. Let’s keep in mind what this device will be used for. It will be used in a commercial gym. This means that the device will be used quite often and it must be very durable. Also, the attachment clamp must be easy to take off and on the barbell. It must be able to clamp around a 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, and 35mm barbell shaft.
You must also think about how this device will be manufactured.
You must also think about how this device will be manufactured.
There is also A 3D STEP file attached.
can you please upload the files with an extension other than .ipt, solidworks is having trouble identifying the files.
Designers, the new design must be able to attach to 25mm, 26mm, 27mm, 28mm, 29mm, 30mm, 31mm, 32mm, 33mm, 34mm and 35mm barbell shafts.
Designers,
I want the new connection design to be quick. No threads. Threads take too long to take off and on.
I want the new connection design to be quick. No threads. Threads take too long to take off and on.
could you upload all fill that you attachment than I can open them on SOLIDWORKS. some files need inventor software to open
rhınoceros can work
ıs rhınoceros work ?
The specification 25mm to 35mm barbell... am I to understand that there are only 2 sizes, 25 and 35? or are there sizes in between?
Hi, must the clamp tightly grip the barbell shaft? I measure the current design diameter is 28mm.
Designers please make sure that your design quick connect will accommodate a 25mm to 35mm diameter smith machine barbell shaft.
Thanks,
Fabian
Thanks,
Fabian
Designers, when submitting ideas; please submit JPG images.
Thanks,
Fabian
Thanks,
Fabian
