Tankless water heaterBlind

in3D Modeling Designheld bygordono
Contest Ended, Winner(s) have been selected.
  • Open
  • Choosing Finalist
  • Ended
Description:
Design a tankless water heater. Something different yet pleasing to the eye. If it was in your home, Laundry room, garage, utility closet. Something futuristic, yet simple and doesn't stand out too much. No buttons or LCD screen. Can have LEDs and so forth to make the design better and stand out a little. The file will need to be able to convert and use. 3D model this and then put it into 3d rendering to make it look good. Use what software you want long as we can utilize the file for later purposes.

First place will continue working with us on the design for including full case design for manufacturing, and other renderings of the design along with the inside for mounting parts.

For now, we are looking for the best design and someone that will be able to help in the area listed above for future work.
Wants:
Can be any shape, size will be in these constraints. MAX 3 feet wide by 3feet long by 1foot depth and Minimum is 1Foot wide 1Foot length and 6Inch depth. must fall into those constraints. If the unit is round then can sacrifice wide length for depth. So you have a lot to work with. Make it simply does not have to be super complex. The unit will need to be able to hand on a wall you will have one inlet one outlet and a power plug-in.

3D rendering after to have as close as possible photo realistic product.
Don't Wants:
Overly complex
Ask for Sample:
One sample of the front and side of the unit.
Additional Information
Add a QR code on unit this is where people will connect the unit through the app. As well as add our logo to the unit. It will be attached.

This is an electric tankless.

** Update ** going to give the design some extra design considerations for flexibility. The depth we are going to expand to 3foot. If the width is taken in. This should help in design flexibility and out-of-the-box ideas.

***Update 2: The unit's temp is controlled by the app. Water flow is not important at this point meaning the connectors inlet and outlet just run at 1/2" or 3/4" pipe. Not important at this stage.
This is going in a home so not industrial.
No need for LCD screens as displays however can add LED however you see fit or cut outs that are see-through etc.
At this stage, we are looking for design.
