Description:
I would like a professional design for a workout machine prototype. I plan to push it into production soon. I attached two very basic drawings to give a super high level overview of what the machine *can* look like. Please review because there are important features in the mock ups that should be included, which is different from many other machines on the market. I’m open to different designs but it must function proficiently as a standing leg extension with the necessary features that are mentioned below. Here are details about the project:- This is a standing leg extension machine.
- The material should be sturdy metal. A strong durable type of steel, something that’s commonly used with well made machinery is fine. It will need to be heavy so that it won’t move under load. The vertical steel supports should have holes on each square side so pegs can be installed if users want to incorporate resistance bands.
- Dimensions are as follows:
- 4 feet tall | 4 feet wide | 6 feet long. Top chest rest: 2 feet long. Bars with handles should be another foot in length, with ability to extend and retract. Small vertical bars should be 2 feet tall with extension and retraction functionality.
- The front of the machine should be longer to compensate for the weight in the rear.
- The steel should be adjustable meaning there should be an inner sleeve for each vertical bar to raise or lower the height. Also include this in the chest rest parallel bars.
- I also want a bi-way tilting option for the parallel chest rest so the individual can bend downward toward the ground or upward for exercise variance.
- There should be another bi-way tilting option at the bottom for the 4 foot vertical bar.
- There should be a supportive pad on the tall 4 foot bar to comfort the belly/ chest area during exercise.
- There will be two foot extensions, each with their own foot roller and supportive pads (two pads per extension). The extension mechanism should be welded into the steel so it’s strong and supported. It will also need to extend and retract to support users with short and long legs. I want it to be connected to the smaller parallel bar with an L shape toward the inner “swing area” of the machine. The end of the L will have a foot roller and right above the foot roller should be two 8” shin pads (one for the left side and another for the right side of the shin). This will support the leg more so, in order to keep the individual from relying on the foot roller alone to perform the extension.
- This will be a cable pulley machine (flat plates included) with a round plate loaded option as well. A peg on each side will be needed to accommodate the round plates.
Wants:
Since I desire to move this machine into production, the design will be key. I need this to compete with the looks and functionality of Life Fitness and Rogue Fitness products - please educate yourself with latest machine build designs and functionality. Must be familiar with equipment aesthetics and machinery, rotary pulls, hinges, bracketing, bearings, caps, support placement, and general machine build mechanics. Color of machine will be in the RGB color model #e59b9c.Thank you for submissions! This really means a lot and looking forward to working with you.
Don't Wants:
过于简单的设计。这可能看起来很便宜和通讯onplace. Machine should be sleek and robust. This should look and perform like a strong competitor in the strength training industry. Quick, average designs will not be enough. I desire to work with someone who has existing knowledge with machinery/engineering design to create a high performing product that is worth the financial investment. Designer thoughtfulness is required.
