Free Standing Floor Rack for 4 pairs of SkisBlind
inConsumer Productsheld bydans3Last seen:
Contest Closed
-
Open
-
Choosing Finalist
-
Ended
Description:
Requirements: Develop a unique, custom-designed free-standing floor rack that holds 4 pairs of skis upright.Compatibility: The ski rack stand should be designed to hold skis of all sizes, including regular, wide (up to 145mm) and cross-country (as narrow as 40mm) models comfortably and securely.
Design: Must have ventilation ports to allow skis to dry and for snow to melt. Must have drainage holes at the bottom to allow melted snow and water to drain out. Rack must stand on its own irrespective of how many skis are inserted (up to limit of 4).
妈terial: Lightweight, durable, non-corroding material. Polycarbonate (PC) plastic is likely most suitable but we are open to others ideas.
Packaging: Ski rack can be knockdown or fully assembled.
Stability: Ski rack stand must be stable and prevent skis from moving or falling over. We are open to having removable extensions that add stability.
Easy Assembly: The ski rack stand should be easy to assemble.
Interconnectability: Each ski rack stand should be able to connect to another ski rack stand. This would allow ski chalets or stores to purchase multiple and have them all interconnected.
妈nufacturing Considerations: We would like to minimize the number of molds that are required. Design should consider the manufacturing process and how best to minimize mold and production costs as well as the potential for complications and defects.
Additional Features: We are open to unique ideas for additional features for the rack stand.
Options: If you have a good design but it works with a different number of skis such as 3, 5 or 6 we are potentially open to this.
Existing Competitors (for reference purposes only we are require a unique design):
Example 1bit.ly/SkiStorageRack1
Example 2:bit.ly/SkiStorageRacks1Connected
Example 3:bit.ly/SkiStorageRack2
For SkiStorageRack1 we made rough CAD drawings as attached. Note we are looking for a unique design, this is an example for reference purposes only.
Format: CAD Files along with STL and STEP format.
First place will continue working with us on the design including full design for mass production.
Wants:
Crtieria is based on satisfying our requirements above. Overall we are looking for functionality, ease of manufacturing and mold development, uniqueness etc.
Don't Wants:
We want a unique design, not a replica of an existing product.
Additional Information
Design & Packaging: (1) Design should minimize packaging volume. For example, do not include parts that protrude that will increase packaging volume but do not add value to the design other than aesthetics.(2) Lower height of the stand with removable supports is preferred over a taller design that will lead to higher packaging volume. Packaging volume minimization is very important.
(3)滑雪板插入我的洞或裂缝nto should would benefit from having something that keeps the skis in place. The skis will be thinner than the hole so keeping them from moving around would be beneficial to the design. An existing competitor has done this if you review the shared design.
(4) Consider that skiis are typically linked together and stored together as a pair. As such, the design should allow for both skis to into one hole or two holes but only a small piece of plastic between the two skiis. The use of two holes with plastic in between is likely a better design as it will keep the skiis more stable and prevent movement.
Prepaid PrizeEntries
#13Free Standing Floor Rack for 4 pairs of Skisbyalexander_kzmnk
Download Files
- 索尔idWorks 2022 — Casting process -01
- Microsoft PowerPoint 2019 — Free Standing Floor Rack for 4 pairs of
- 索尔idWorks 2022 — Casting process
- 索尔idWorks 2022 — Free Standing Floor Rack for 4 pairs of Skis -01
- 索尔idWorks 2022 — Free Standing Floor Rack for 4 pairs of Skis
- 索尔idWorks 2022 — Free Standing Floor Rack for 4 pairs of Skis -02
Apr 30, 2023 2:00
#121st Concept Design Free Standing Floor Rack Skis 5 PairsbyChaniago
Download Files
Apr 27, 2023 9:49
Discussion
Apparently the customer was not interested in any of our developments.
I have sent 3 designs, if you want further amendment in the design ask for free assistance.
Do you want to open another contest to get more detailed results?
We prefer a design that can stand on its own and hold 4-6 pairs of skiis. We are opening to different idea showever.
Hi Dan,
Do the stand need to be modular, i mean Should multiple stands be placed side by side or a design which is stand alone and can hold 4 pais of ski work
Do the stand need to be modular, i mean Should multiple stands be placed side by side or a design which is stand alone and can hold 4 pais of ski work
Hi gopinathr1, the rack should be designed to hold 4 pairs of skiis but if you can only do a design that holds 5 or 6 pairs of skiis we are open to that. Each port in the rack should be able to fit any type of ski.
I mean "six pairs of skis"
Hi Dan, I have a few doubts about which I need your clarification.
Q1:
(Compatibility: The ski rack stand should be designed to hold skis of all sizes, including regular, wide (up to 145 mm), and cross-country (as narrow as 40 mm) models, comfortably and securely.)
Do you mean that each port in the rack must be able to house a pair of skis of any size or
You want one rack to have four ports of different sizes, each capable of housing a ski pair of one particular size, so that a rack can house four different sizes of skis.
Q2:
(选项:如果你有一个好的设计,但它的工作原理ith a different number of skis, such as 3, 5, or 6, we are potentially open to this.)
Do you want a rack to have a maximum of six ports so that it can house six skis?
Please clarify.
Q1:
(Compatibility: The ski rack stand should be designed to hold skis of all sizes, including regular, wide (up to 145 mm), and cross-country (as narrow as 40 mm) models, comfortably and securely.)
Do you mean that each port in the rack must be able to house a pair of skis of any size or
You want one rack to have four ports of different sizes, each capable of housing a ski pair of one particular size, so that a rack can house four different sizes of skis.
Q2:
(选项:如果你有一个好的设计,但它的工作原理ith a different number of skis, such as 3, 5, or 6, we are potentially open to this.)
Do you want a rack to have a maximum of six ports so that it can house six skis?
Please clarify.
I mistakenly submitted the wrong file, who to delete it, please help
Do you prefer any specific material of the racks?
